Technical Specifications
Detailed specifications of our systems and products for converting waste tires into energy
Reactor Specifications
Type: Vertical Reactor
Heating Method: Electric Resistance
Operating Temperature: 400°C
Atmosphere: Oxygen-Free
Safety: No Flame, No Moving
Features: Connections
Product Specifications
Pyrolysis Oil Density: 919 kg/m³ @27°C
Flash Point: 69°C
Calorific Value: 42.79 MJ/kg
Sulfur Content: 1.93% (Crude)
Steel Wire Carbon: 0.32-0.39%
Emission Control
Air Washers: Nano-Cation Technology
Filtration: Multiple Stage
Byproducts: Environmentally Friendly Salts
SO2 Conversion: Sodium Sulfite
CO2 Conversion: Sodium Bicarbonate
System Overview
Our system is designed to convert waste tires into energy and marketable products using the latest environmentally friendly technologies.
The system relies on advanced pyrolysis technology in an oxygen-free environment to ensure high efficiency and minimal emissions.
Our system features vertical reactor design that provides the highest levels of safety and efficiency, using electric heating instead of open flame to avoid any fire or explosion risks.
Our emission control system ensures that all gases and byproducts are fully processed, resulting in environmentally friendly salts that can be used in other industries.
